Product Overview

TiraThai, a specialized sub-brand of Jinguan Electric dedicated to transformer and electrical equipment innovations, proudly introduces the ZBW-12 Series Combined Box-Type Substation. This prefabricated, modular unit integrates high-voltage switchgear, transformers (oil-immersed or dry-type), and low-voltage distribution equipment into a compact, factory-assembled enclosure, designed for AC 50Hz systems with rated voltages of 12kV on the high-voltage side and 0.4kV on the low-voltage side. Ideal for urban high-rise buildings, residential areas, industrial parks, mines, oil fields, and construction sites, the ZBW-12 series provides reliable power reception and distribution with a focus on compactness and flexibility.

Jinguan Electric, founded in 1979 as a high-tech enterprise in Nanyang City, Henan Province, China, has evolved from pioneering arrester manufacturing to a global leader in high-voltage transmission and distribution equipment. Embracing Industry 4.0 principles, Jinguan Electric drives core competitiveness through continuous innovation, with TiraThai serving as its premier brand for combined substation solutions. This sub-brand channels Jinguan Electric's expertise into customizable ZBW-12 substations that prioritize safety, efficiency, and environmental adaptability, complying with international standards such as IEC 62271-202, GB/T 17467, and IEEE C37. Certified by UL, cUL, CSA, SGS, CCC, CQC, CTQC, and CE, these units uphold ISO9001 (quality), ISO14001 (environmental), and ISO45001 (health & safety) management systems, backed by a minimum two-year warranty, comprehensive factory acceptance testing (FAT), and dedicated after-sales engineering support for global deployments.

The ZBW-12 series features a robust, corrosion-resistant enclosure with IP54 protection, ensuring durability in harsh environments. Its modular design supports flexible layouts like "目" or "品" shapes, reducing footprint by 30-40% compared to conventional substations. With high overload capacity and low noise, it is tailored for urban and industrial applications. TiraThai's philosophy—"dig 100 meters deep in 1 meter of space"—reflects Jinguan Electric's commitment to precision, delivering substations that minimize installation costs and maximize grid resilience for modern power infrastructure.

Substation Model: ZBW-12 Series Rated Voltage: HV 12kV / LV 0.4kV Frequency: 50Hz

This modular design makes TiraThai's ZBW-12 Series a cornerstone for efficient, reliable power distribution.

Key Features and Engineering Excellence

TiraThai's ZBW-12 Series Combined Box-Type Substation is engineered for superior performance, integrating high-voltage switchgear, transformers, and low-voltage distribution in a compact, prefabricated unit. The corrosion-resistant enclosure, made from stainless steel or treated composite materials, provides IP54 protection against dust, moisture, and harsh weather, ensuring maintenance-free operation in challenging environments. The modular design allows customizable layouts ("目" or "品" shapes) for space-constrained sites, reducing footprint by 30-40%.

The substation supports high overload capacity (up to 120% short-term) and low noise levels (under 55dB), making it ideal for urban residential areas. Integrated monitoring components, such as voltage and current sensors, enable real-time diagnostics, with optional “four remote” functions (telemetry, remote signaling, adjustment, control) for smart grid integration. Jinguan Electric's automated production—featuring robotic assembly, vacuum testing, and AI-driven inspections—guarantees defect-free units with robust construction for seismic and wind resistance.

Compared to traditional substations, TiraThai ZBW-12 units reduce installation time by 40% and costs by 25%, with energy savings of 15-20% through optimized components. Optional features like SCADA integration and surge protection enhance reliability. These attributes not only meet but exceed GB/T 17467 and IEC 62271-202 standards, providing a substation that balances compactness, safety, and scalability.

Technical Specifications

TiraThai's ZBW-12 Series is precision-engineered for versatility, with baseline specs expandable through customization. Below is a detailed table of key parameters, based on Jinguan Electric's validated testing and compliant with GB/T 17467, IEC 62271-202, and IEEE C37 standards.

ParameterSpecification Details
Rated Voltage (kV)HV: 12; LV: 0.4
Frequency (Hz)50
Transformer Capacity (kVA)Customizable (e.g., 100-1600)
High-Voltage EquipmentLoad Switch / Circuit Breaker (Customizable)
Low-Voltage EquipmentDistribution Panels (GGD / MNS, Customizable)
Enclosure ProtectionIP54 (Corrosion-Resistant, Dustproof, Waterproof)
Noise Level (dB, 1m)≤55
Operating Temperature (°C)-30 to +40
Operating Humidity (% RH)Daily Avg. ≤95%; Monthly Avg. ≤90%
Wind Resistance (Pa)700
Seismic Acceleration (m/s²)Horizontal ≤0.4; Vertical ≤0.15
Efficiency (%)>98 (Integrated System)
Short-Circuit Withstand25kA / 2s
Dimensions (m, approx. 500kVA)Length: 3-4; Width: 2.5; Height: 2.6 (Customizable)
Weight (tons, approx. 500kVA)3-5

These metrics support altitudes up to 1000m, with full type testing for thermal cycling, dielectric strength, and environmental resilience. Custom options include dry-type transformers and SCADA integration.

Applications and Performance Benefits

TiraThai's ZBW-12 Series is ideal for urban high-rise buildings, residential areas, industrial parks, mines, oil fields, and construction sites. In urban settings, its compact design powers residential and commercial loads with minimal space use. Industrial sites like mines and oil fields benefit from corrosion-resistant enclosures for harsh conditions, while construction sites leverage rapid installation for temporary power.

The series supports ring network, dual power, or radiation terminal systems for grid flexibility. Jinguan Electric's deployments yield 99.95% uptime, 20-30% space savings, and MTBF over 50,000 hours, fostering resilient networks.

Why Choose TiraThai by Jinguan Electric?

TiraThai, as Jinguan Electric's sub-brand, delivers combined substation excellence backed by 45+ years of innovation. Our ZBW-12 series offers modular compactness, high overload capacity, and full customization, surpassing standards. With UL/CE certifications, we ensure 25% cost savings and reliable power for global grids.

Expanded FAQ Section

How are TiraThai substations shipped internationally? Shipped via sea, rail, or truck for global delivery. Prefabricated units in bulk packaging for stability, accessories in wooden cases to withstand transit stresses.

Can TiraThai products be customized? Yes, tailored for voltage, frequency, and equipment configurations through Jinguan Electric's engineering team.

What warranty do you provide? At least two years comprehensive coverage for defects, performance, and materials, with extensions available.

Is Factory Acceptance Testing (FAT) supported? Standard: Full electrical, thermal, and integration tests per unit, with client witnessing in-person or remotely.

Do you provide after-sales engineering support? Yes, Jinguan Electric deploys engineers for on-site installation, commissioning, troubleshooting, and audits.

What makes the ZBW-12 design superior? Modular layout and sealed enclosure reduce footprint by 30-40% and ensure maintenance-free operation.

Are they suitable for renewables? Yes, customizable for solar/wind with overload capacity and low noise for grid integration.

Certifications and Quality Assurance

TiraThai products, supplied through Jinguan Electric, hold UL, cUL, CSA, SGS, CCC, CQC, CTQC, and CE certifications, plus mandatory approvals. Systems certified to ISO9001 (quality), ISO14001 (environment), and ISO45001 (health & safety), ensuring GB/T 17467, IEC 62271-202, and IEEE C37 compliance for global excellence.

Contact Us Today

Distribute power efficiently with TiraThai's ZBW-12 Series Combined Box-Type Substation. For quotes or consultations:

Our team responds within 24 hours.
