TiraThai, a specialized sub-brand of Jinguan Electric dedicated to transformer and electrical equipment innovations, proudly introduces the HV Switchgear. This high-voltage electrical equipment solution is designed for reliable power distribution, fully compliant with GB3906-199 "3-35kV AC Metal-Enclosed Switchgear" standards. Comprising a robust cabinet and integrated circuit breaker, the HV Switchgear supports versatile functions including overhead inlet/outlet, cable inlet/outlet, and bus connections. The cabinet integrates a durable shell, electrical components, mechanisms, secondary terminals, and connections, ensuring seamless performance in demanding environments.
Jinguan Electric, founded in 1979 as a high-tech enterprise in Nanyang City, Henan Province, China, has evolved from pioneering arrester manufacturing to a global leader in high-voltage transmission and distribution equipment. Embracing Industry 4.0 principles, Jinguan Electric drives core competitiveness through continuous innovation, with TiraThai serving as its premier brand for HV switchgear solutions. This sub-brand channels Jinguan Electric's expertise into customizable, compact HV switchgear that prioritizes safety, adaptability, and efficiency, meeting international standards such as IEC 62271-200 and IEEE C37.20.2. Certified by UL, CUL, CSA, SGS, CCC, CQC, CTQC, and CE, these switchgear units uphold ISO9001 (quality), ISO14001 (environmental), and ISO45001 (health & safety) management systems, backed by a minimum two-year warranty, comprehensive factory acceptance testing (FAT), and dedicated after-sales engineering support for global installations.
TiraThai's HV Switchgear is engineered for 3-35kV AC applications, with modular designs supporting over 198 main wiring schemes for flexible deployment. Customizable for voltage, frequency, and regional specialties, it accommodates domestic ZN85-40.5 vacuum circuit breakers, French SF1/SF2 SF6 types, and FP system sulfur hexafluoride breakers. Operating reliably in ambient temperatures from -40°C to +40°C and humidity up to 95% RH, the switchgear facilitates unmanned operation with minimal maintenance. TiraThai's design philosophy—"dig 100 meters deep in 1 meter of space"—reflects Jinguan Electric's commitment to precision, delivering compact, durable solutions that minimize footprint while maximizing safety and uptime for utilities and industries worldwide.
Switchgear Model: Custom HV Series Rated Voltage: 3-35kV AC Frequency: 50/60Hz
This versatility makes TiraThai's HV Switchgear an essential choice for efficient, resilient power control in diverse global applications.
Key Features and Engineering Excellence
TiraThai's HV Switchgear excels through its innovative, modular architecture, balancing compactness with superior safety and adaptability. The compact structure reduces floor space by up to 30% compared to traditional designs, while surface treatments like spraying or galvanizing ensure corrosion resistance and longevity in harsh environments. Each functional chamber is sealed by metal plates with independent pressure release channels, preventing arc propagation and enhancing personnel safety during faults.
Compatibility extends to advanced breakers: domestic ZN85-40.5 vacuum types for eco-friendly, maintenance-free operation; French SF1/SF2 SF6 for high-reliability arc quenching; and FP system SF6 for compact, high-performance interruption. The design supports door-closed operation, strong structural adaptability for over 198 wiring schemes, and complete "five prevention" functions—including anti-misoperation, live interval verification, and anti-error grounding—ensuring foolproof reliability.
Jinguan Electric's automated production—featuring precision welding, vacuum testing, and AI-driven quality inspections—guarantees defect-free assembly, with material options like cold-rolled steel, aluminum-zinc sheets, stainless steel, or aluminum plates for non-magnetic needs. Optional features such as integrated relays, surge arresters, and SCADA interfaces enable smart grid integration. Compared to conventional switchgear, TiraThai units offer 20-25% faster installation and lower lifecycle costs through modular scalability. These attributes not only comply with GB3906-199 but exceed it, providing users with a switchgear that thrives in high-stakes power distribution.
Technical Specifications
TiraThai's HV Switchgear is precision-engineered for versatility, with baseline specs expandable through customization. Below is a detailed table of key parameters, validated through Jinguan Electric's certified testing and compliant with GB3906-199, IEC 62271-200, and IEEE C37.20.2 standards.
| Parameter | Specification Details |
|---|---|
| Rated Voltage (kV) | 3 / 6 / 10 / 20 / 35 AC |
| Frequency (Hz) | 50/60 |
| Breaker Compatibility | ZN85-40.5 (vacuum), SF1/SF2 (SF6), FP system (SF6) |
| Wiring Schemes Supported | >198 main schemes (customizable) |
| Enclosure Material | Cold-rolled steel, aluminum-zinc sheet, stainless steel, aluminum plate (non-magnetic options) |
| Surface Treatment | Spraying or galvanizing (corrosion-resistant) |
| Functional Chambers | Main busbar room, circuit breaker room, cable room, relay/instrument room, small busbar room |
| Sealing & Protection | Metal plate sealed chambers; independent pressure release channels |
| Safety Functions | Complete "five prevention" (anti-misoperation, live verification, etc.) |
| Operating Temperature (°C) | -40 to +40 |
| Operating Humidity (% RH) | ≤95 (non-condensing) |
| Short-Circuit Withstand | 40kA / 2s (integrated) |
| Noise Level (dB, 1m) | ≤60 |
| Enclosure Protection | IP54 (weatherproof, dustproof) |
| Dimensions (m, approx. standard bay) | Width: 0.8-1.2; Depth: 1.5-2.0; Height: 2.2-2.5 (customizable) |
| Weight (kg, approx. standard bay) | 800-1500 (modular) |
These metrics support altitudes up to 1000m, with full type testing for arc fault containment, dielectric strength, and seismic resilience (up to 0.5g). Custom options include SF6-free vacuum breakers for eco-compliance.
Applications and Real-World Performance
TiraThai's HV Switchgear is tailored for high-voltage power control in utilities and industries, excelling in scenarios requiring compact, adaptable distribution. In power plants and substations, it manages overhead/cable inlets and bus connections for efficient load switching, supporting grid stability with over 198 wiring options. Industrial facilities like factories and mining sites deploy it for fault isolation and overcurrent protection, ensuring continuous operation amid heavy loads.
Urban infrastructure, such as metro systems and commercial complexes, benefits from the space-saving design and door-closed operation, minimizing disruptions during maintenance. Renewable energy tie-ins, including wind farms, integrate it for HV busbar management, handling variable inputs with robust short-circuit withstand. Jinguan Electric's global deployments yield 99.95% uptime, 20% reduced footprint, and MTBF over 80,000 hours, ideal for resilient networks in diverse climates.
Why Choose TiraThai by Jinguan Electric?
TiraThai, as Jinguan Electric's sub-brand, delivers HV switchgear excellence backed by 45+ years of innovation. Our units offer compact modularity, "five prevention" safety, and full customization, surpassing standards. With UL/CSA certifications and sustainable materials, we ensure 25% faster deployment and lower TCO for global users.
Expanded FAQ Section
How are TiraThai switchgear shipped internationally? Shipped via sea, rail, or truck for global delivery. Modular bays in bulk packaging for stability, breakers in wooden cases to withstand transit stresses.
Can TiraThai products be customized? Yes, tailored for voltage, frequency, breaker types, and wiring schemes through Jinguan Electric's engineering team.
What warranty do you provide? At least two years comprehensive coverage for defects, performance, and materials, with extensions available.
Is Factory Acceptance Testing (FAT) supported? Standard: Full electrical, mechanical, and safety tests per unit, with client witnessing in-person or remotely.
Do you provide after-sales engineering support? Yes, Jinguan Electric deploys engineers for on-site installation, commissioning, troubleshooting, and audits.
What are the "five prevention" functions? Anti-misoperation, live interval verification, anti-error grounding, accidental closing prevention, and live part entry prevention for ultimate safety.
Are SF6-free options available? Yes, vacuum breakers like ZN85-40.5 for eco-friendly, maintenance-free operation.
Certifications and Quality Assurance
TiraThai products, supplied through Jinguan Electric, hold UL, CUL, CSA, SGS, CCC, CQC, CTQC, and CE certifications, plus mandatory approvals. Systems certified to ISO9001 (quality), ISO14001 (environment), and ISO45001 (health & safety), ensuring GB3906-199, IEC 62271-200, and IEEE C37.20.2 compliance for global excellence.
