Product Overview
TiraThai, a specialized sub-brand of Jinguan Electric dedicated to transformer and electrical equipment innovations, proudly introduces the Electroslag Furnace Transformers. These advanced units are designed for the precise melting and refining of steel produced by conventional smelting methods, enabling the production of high-quality materials such as aviation bearing steel, high-temperature alloys, resistance alloys, precision alloys, and various non-ferrous metals. They also support the creation of large-scale alloy steel ingots, massive flat ingots or slabs weighing hundreds of tons, and other specially shaped castings through electroslag furnace power supply.
Jinguan Electric, founded in 1979 as a high-tech enterprise in Nanyang City, Henan Province, China, has evolved from pioneering arrester manufacturing to a global leader in high-voltage transmission and distribution equipment. Embracing Industry 4.0 principles, Jinguan Electric drives core competitiveness through continuous innovation, with TiraThai serving as its premier brand for electroslag furnace transformer solutions. This sub-brand channels Jinguan Electric's expertise into customizable, high-efficiency transformers that differ from electric arc furnace types, focusing on low no-load voltage and small impedance for arc-free electroslag processes post-initial stage. Certified by UL, CUL, CCC, CQC, CTQC, CE, and SGS, these units uphold ISO9001 (quality), ISO14001 (environmental), and ISO45001 (health & safety) management systems, ensuring superior performance and sustainability.
The TiraThai Electroslag Furnace Transformers are available in single-phase (generally preferred) and three-phase configurations, with voltage regulation on the low-voltage side via series connection. Adjustment methods include no-excitation no-load, excitation no-load, or on-load voltage regulation, all controlled by a switch on the high-voltage coil. Customizable for voltage, frequency, and regional specialties, they integrate seamlessly into metallurgical workflows. TiraThai's philosophy—"dig 100 meters deep in 1 meter of space"—reflects Jinguan Electric's commitment to precision, delivering transformers that optimize refining efficiency and material quality for advanced industrial applications.
Transformer Model: Custom Electroslag Series Power Supply Type: Single-Phase / Three-Phase Frequency: 50/60Hz
This specialized design makes TiraThai's Electroslag Furnace Transformers indispensable for high-precision metallurgy worldwide.
Key Features and Engineering Excellence
TiraThai's Electroslag Furnace Transformers are engineered for precision and reliability, featuring low no-load voltage and small impedance voltage to support arc-free electroslag processes after the initial arcing stage. The single-winding configuration ensures stable power supply to consumable electrodes, minimizing variations in slag pool dynamics and reducing defects in refined materials. Voltage regulation on the low-voltage side via series connection provides flexible adjustment, with options for no-excitation no-load, excitation no-load, or on-load methods controlled by a high-voltage coil switch for seamless operation.
The core utilizes high-permeability silicon steel with optimized stacking for low losses, paired with oxygen-free copper windings for high conductivity and thermal stability. Oil immersion facilitates superior cooling (ONAN), maintaining Class A insulation under overloads up to 120%. Jinguan Electric's automated production—featuring precision winding, vacuum oil-filling, and AI inspections—guarantees defect-free assembly, with robust enclosures for weather resistance (IP54 rated).
Compared to arc furnace transformers, TiraThai electroslag units offer 15-20% better arc control and energy efficiency, extending electrode life and improving yield rates. Optional features like integrated monitoring and surge protection enhance safety. These attributes not only meet but exceed IEC 60076 and GB 1094 standards, providing metallurgists with a transformer that ensures consistent, high-quality output.
Technical Specifications
TiraThai's Electroslag Furnace Transformers are precision-engineered for metallurgical demands, with baseline specs expandable through customization. Below is a detailed table of key parameters, based on Jinguan Electric's validated testing and compliant with IEC 60076, GB 1094, and IEEE C57 standards.
| Parameter | Specification Details |
|---|---|
| Rated Capacity (kVA) | Customizable (e.g., 50-5000 for single-phase) |
| Primary Voltage (kV) | Up to 35 (customizable) |
| Secondary Voltage (V) | Low-voltage series regulation (customizable) |
| Frequency (Hz) | 50/60 |
| Power Supply Type | Single-Phase (preferred) / Three-Phase |
| Impedance Voltage (%) | Small (4-6%, customizable) |
| No-Load Voltage | Low (optimized for electroslag) |
| Voltage Regulation Method | No-excitation no-load, excitation no-load, or on-load (HV coil switch) |
| Insulation Class | Class A (105°C rise) |
| Cooling Method | ONAN |
| Noise Level (dB, 1m) | ≤60 |
| Enclosure Protection | IP54 (weatherproof) |
| Efficiency (%) | >98 at full load |
| Short-Circuit Withstand | 40kA / 2s |
| Operating Temperature (°C) | -20 to +50 |
| Weight (tons, approx. 1000kVA) | 2-4 |
These metrics support altitudes up to 1000m, with full routine testing for thermal cycling and dielectric strength. Custom options include three-phase variants.
Applications and Performance Benefits
TiraThai's Electroslag Furnace Transformers are essential for refining steel and alloys in metallurgy, producing aviation bearing steel, high-temperature alloys, resistance alloys, precision alloys, and non-ferrous metals. They enable large-scale alloy ingots, massive slabs, and special castings via electroslag remelting, with low impedance ensuring stable, arc-free processes for minimal impurities and high yields.
In steelmaking, they support electroslag metallurgy for premium materials, reducing defects by 15-20%. Jinguan Electric's deployments yield MTBF over 50,000 hours and 20% energy savings, fostering sustainable production.
Why Choose TiraThai by Jinguan Electric?
TiraThai, as Jinguan Electric's sub-brand, delivers electroslag excellence backed by 45+ years of innovation. Our series offers low impedance, flexible regulation, and full customization, surpassing standards. With UL/CE certifications, we ensure 25% higher yields and lower TCO for global metallurgy.
Expanded FAQ Section
How are TiraThai transformers shipped internationally? Shipped via sea, rail, or truck for global delivery. Main body in bulk packaging for stability, accessories in wooden cases to withstand transit stresses.
Can TiraThai products be customized? Yes, tailored for voltage, frequency, and regulation methods through Jinguan Electric's engineering team.
What warranty do you provide? At least two years comprehensive coverage for defects, performance, and materials, with extensions available.
Is Factory Acceptance Testing (FAT) supported? Standard: Full electrical, thermal, and mechanical tests per unit, with client witnessing in-person or remotely.
Do you provide after-sales engineering support? Yes, Jinguan Electric deploys engineers for on-site installation, commissioning, troubleshooting, and audits.
What sets electroslag apart from arc furnaces? Arc-free post-initial stage, low voltage/impedance for precise refining of high-quality alloys.
Are three-phase options available? Yes, for larger-scale production alongside preferred single-phase designs.
Certifications and Quality Assurance
TiraThai products, supplied through Jinguan Electric, hold UL, CUL, CCC, CQC, CTQC, CE, and SGS certifications, plus mandatory approvals. Systems certified to ISO9001 (quality), ISO14001 (environment), and ISO45001 (health & safety), ensuring IEC 60076, GB 1094, and IEEE C57 compliance for global excellence.
Contact Us Today
Refine your metallurgy with TiraThai's Electroslag Furnace Transformers. For quotes or consultations:
- WhatsApp: +8613037600603
- Email: [email protected] or [email protected]
Our team responds within 24 hours.
