Product Overview
TiraThai, a specialized sub-brand of Jinguan Electric dedicated to transformer and electrical equipment innovations, proudly introduces the 110kV Oil-Immersed Transformers. These high-voltage units are essential for step-up and step-down conversion in power systems, featuring excellent insulation performance and large capacity to meet the demands of modern grids. Widely used in utilities, industrial facilities, and transmission networks, the 110kV series ensures stable, efficient energy transfer with robust construction for long-term reliability.
Jinguan Electric, founded in 1979 as a high-tech enterprise in Nanyang City, Henan Province, China, has evolved from pioneering arrester manufacturing to a global leader in high-voltage transmission and distribution equipment. Embracing Industry 4.0 principles, Jinguan Electric drives core competitiveness through continuous innovation, with TiraThai serving as its premier brand for oil-immersed transformer solutions. This sub-brand channels Jinguan Electric's expertise into customizable 110kV transformers that prioritize high efficiency, strong heat dissipation, and short-circuit resistance, complying with international standards such as IEC 60076, GB 1094, and IEEE C57.12.00. Certified by UL, CUL, CCC, CQC, CTQC, CE, and SGS, these units uphold ISO9001 (quality), ISO14001 (environmental), and ISO45001 (health & safety) management systems, ensuring superior performance in diverse applications.
The 110kV Oil-Immersed Transformers support three-phase configurations with customizable capacities from 31.5MVA to 300MVA, operating at 50/60Hz. Their durable oil insulation provides outstanding dielectric strength and cooling, making them indispensable for power systems requiring large-scale energy conversion. TiraThai's philosophy—"dig 100 meters deep in 1 meter of space"—reflects Jinguan Electric's commitment to precision, delivering transformers that optimize reliability and minimize operational costs for sustainable power infrastructure.
Transformer Model: Custom 110kV Series Primary Voltage Ratings: 110kV (Customizable) Rated Frequency: 50/60Hz
This high-capacity design makes TiraThai's 110kV Oil-Immersed Transformers a cornerstone for efficient, resilient power systems worldwide.
Key Features and Engineering Excellence
TiraThai's 110kV Oil-Immersed Transformers are engineered for excellence, featuring high insulation performance through premium mineral oil immersion, which provides superior dielectric strength and heat dissipation for continuous operation. The large capacity supports high-throughput energy transfer, while high efficiency minimizes losses, achieving >98% at full load. Strong heat dissipation via natural convection (ONAN) maintains thermal stability, even under overloads up to 120% short-term.
The robust construction includes grain-oriented silicon steel cores with stepped-lap joints for low hysteresis losses and oxygen-free copper windings for reduced resistance and enhanced short-circuit withstand (40kA/2s). Corrosion-resistant tanks and sealed designs ensure longevity in harsh environments, from humid coasts to dusty industrial sites. Jinguan Electric's automated production—featuring precision winding, vacuum oil-filling, and AI inspections—guarantees defect-free assembly, with optional on-load tap changers (OLTC) for voltage regulation.
Compared to air-cooled alternatives, TiraThai units offer 15-20% better thermal management and extended lifespan (over 30 years), with low noise (under 60dB) for urban compatibility. These features not only meet but exceed IEC 60076 and GB 1094 standards, providing users with a transformer that balances capacity, efficiency, and durability.
Technical Specifications
TiraThai's 110kV Oil-Immersed Transformers are precision-engineered for versatility, with baseline specs expandable through customization. Below is a detailed table of key parameters, based on Jinguan Electric's validated testing and compliant with IEC 60076, GB 1094, and IEEE C57 standards.
| Parameter | Specification Details |
|---|---|
| Rated Capacity (MVA) | 31.5-300 (customizable) |
| Primary Voltage (kV) | 110 (Y connection; customizable to 66/132) |
| Secondary Voltage (kV) | 10 / 20 / 35 (Dyn11 or YNd1) |
| Frequency (Hz) | 50/60 |
| No-Load Loss (kW) | 31.5MVA: 20; 100MVA: 45 (low-loss core) |
| Load Loss (kW, at 75°C) | 31.5MVA: 150; 100MVA: 400 (copper-optimized) |
| Impedance Voltage (%) | 10-14% (capacity-dependent) |
| Insulation Level | LI200/AC95kV |
| Cooling Method | ONAN/ONAF; OFAF optional |
| Noise Level (dB, 1m) | ≤65 at full load |
| Enclosure Protection | IP54 (weatherproof) |
| Efficiency (%) | >98 at full load |
| Short-Circuit Withstand | 40kA / 2s |
| Weight (tons, approx. 100MVA) | Total: 120-150 |
These metrics support altitudes up to 1000m, with full routine testing for thermal cycling and dielectric strength. Custom enhancements include OLTC and eco-oils.
Applications and Performance Benefits
TiraThai's 110kV Oil-Immersed Transformers are vital for step-up/down conversion in power systems, industrial/mining enterprises, transportation, postal/telecom, and research institutions. In utilities, they interconnect transmission lines, ensuring stable high-voltage supply. Industrial sites like mining operations use them for heavy loads, with strong short-circuit resistance preventing outages.
Transportation and telecom facilities benefit from large capacity for reliable backup power. Jinguan Electric's deployments yield 99.95% uptime, 15-20% efficiency gains, and MTBF over 50,000 hours, fostering resilient networks.
Why Choose TiraThai by Jinguan Electric?
TiraThai, as Jinguan Electric's sub-brand, delivers oil-immersed excellence backed by 45+ years of innovation. Our 110kV series offers large capacity, high insulation, and full customization, surpassing standards. With UL/CE certifications, we ensure 20% lower TCO for durable power.
Expanded FAQ Section
How are TiraThai transformers shipped internationally? Shipped via sea, rail, or truck for global delivery. Main body in bulk packaging for stability, accessories in wooden cases to withstand transit stresses.
Can TiraThai products be customized? Yes, tailored for voltage, frequency, and regional needs through Jinguan Electric's engineering team.
What warranty do you provide? At least two years comprehensive coverage for defects, performance, and materials, with extensions available.
Is Factory Acceptance Testing (FAT) supported? Standard: Full electrical, thermal, and mechanical tests per unit, with client witnessing in-person or remotely.
Do you provide after-sales engineering support? Yes, Jinguan Electric deploys engineers for on-site installation, commissioning, troubleshooting, and audits.
What makes them high-capacity? Optimized oil immersion and copper windings support 31.5-300MVA for large-scale step-up/down.
Are they suitable for renewables? Yes, customizable for inverter outputs with overload capacity and low losses.
Certifications and Quality Assurance
TiraThai products, supplied through Jinguan Electric, hold UL, CUL, CCC, CQC, CTQC, CE, and SGS certifications, plus mandatory approvals. Systems certified to ISO9001 (quality), ISO14001 (environment), and ISO45001 (health & safety), ensuring IEC 60076, GB 1094, and IEEE C57 compliance for global excellence.
Contact Us Today
Power your systems with TiraThai's S Series 35kV-66kV Oil-Immersed Transformers. For quotes or consultations:
- WhatsApp: +8613037600603
- Email: [email protected] or [email protected]
Our team responds within 24 hours.
