Jinguan Electric, founded in 1979 as a high-tech enterprise in Nanyang City, Henan Province, China, has evolved from pioneering arrester manufacturing to a global leader in high-voltage transmission and distribution equipment. Embracing Industry 4.0 principles, Jinguan Electric drives core competitiveness through continuous innovation, with TiraThai serving as its focused brand for specialized transformer solutions. This sub-brand channels Jinguan Electric's expertise into eco-friendly, high-efficiency autotransformers that comply with international standards such as VDE0550, IEC439, JB5555, and GB226. Certified by UL, CUL, CCC, CQC, CTQC, CE, and SGS, these transformers uphold ISO9001 (quality), ISO14001 (environmental), and ISO45001 (health & safety) management systems, ensuring seamless global deployment.
TiraThai's Autotransformers are versatile, supporting customizable voltage and frequency adaptations for diverse grids, from 50Hz European systems to 60Hz North American networks. With insulation resistance ≥150MΩ and overcurrent protection, they operate reliably in temperatures from -20°C to +45°C and humidity up to 95% RH (non-condensing), free from corrosive gases or conductive dust. TiraThai's design philosophy—"dig 100 meters deep in 1 meter of space"—reflects Jinguan Electric's commitment to precision, delivering compact, durable units that minimize footprint while maximizing uptime. Whether for step-up/step-down voltage regulation or load balancing, these transformers provide a cost-effective, distortion-free solution for modern power needs.
Transformer Model: Custom Autotransformer Series Primary Voltage Ratings: Customizable (e.g., up to 35kV, based on application) Secondary Voltage Ratings: Customizable (single-winding configuration) Rated Capacity: Customizable (e.g., 100-5000kVA) Rated Frequency: 50/60Hz
This flexibility positions TiraThai's autotransformers as an essential choice for efficient, low-maintenance power transformation across industries.
Key Features and Engineering Excellence
TiraThai's Autotransformers excel through their innovative single-winding architecture, which reduces material usage and complexity while preserving performance integrity. The core design utilizes high-permeability silicon steel laminations with precise stacking to minimize losses, achieving efficiency >98% at full load. Windings are constructed from oxygen-free copper or aluminum, ensuring low resistance and high overload capacity (up to 120% short-term), with epoxy resin or VPI insulation for superior dielectric strength and thermal stability. Overcurrent protection integrates seamlessly, safeguarding against faults without interrupting operations, while the dry-type air cooling (AN mode) supports natural convection for quiet, maintenance-free performance.
No additional waveform distortion is introduced, thanks to balanced magnetic flux paths, making these transformers suitable for precision applications where power quality is critical. Insulation resistance exceeds 150MΩ, verified through rigorous testing, ensuring reliability in humid or dusty environments. Jinguan Electric's automated production lines—featuring robotic winding, vacuum drying, and AI-driven inspections—guarantee defect-free assembly, with optional forced air (AF) cooling for enhanced capacity in high-demand scenarios. Compared to two-winding alternatives, TiraThai autotransformers offer 20-30% material savings and simpler installation, reducing costs without compromising safety or longevity (over 30 years service life).
Safety features include flame-retardant materials (UL94 V-0 rated) and explosion-proof enclosures, aligning with global benchmarks. Optional smart monitoring via PT100 sensors and remote diagnostics enables predictive maintenance, further extending operational reliability. These attributes not only comply with VDE0550, IEC439, JB5555, and GB226 but exceed them, providing users with a compact, distortion-free transformer that enhances system efficiency and reduces total ownership costs.
Technical Specifications
TiraThai's autotransformers are precision-engineered for versatility, with baseline specs customizable to client needs. Below is a detailed table of key parameters, derived from Jinguan Electric's validated testing and compliant with VDE0550, IEC439, JB5555, and GB226 standards. Exact values adapt to customization requests.
| Parameter | Specification Details |
|---|---|
| Rated Capacity (kVA) | Customizable (e.g., 100-5000) |
| Primary Voltage (kV) | Customizable (e.g., 6-35) |
| Secondary Voltage (kV) | Customizable (single-winding ratio) |
| Frequency (Hz) | 50/60 |
| Insulation Resistance (MΩ) | ≥150 (at 1000V DC) |
| Winding Material | Oxygen-free copper / Aluminum (customizable) |
| Connection Type | Yyn0 or Dyn11 (customizable) |
| Insulation Class | Class F (155°C); H (180°C) optional |
| Cooling Method | AN (Natural Air); AF optional |
| No-Load Loss (W) | Optimized (20-30% below standards) |
| Load Loss (W, at 75°C) | Optimized (e.g., 1000kVA: 7000) |
| Impedance Voltage (%) | 4-6% (capacity-dependent) |
| Noise Level (dB, 1m) | ≤55 |
| Enclosure Protection | IP20 standard; IP54 optional |
| Efficiency (%) | >98 at full load |
| Short-Circuit Withstand | 25x rated current / 2s |
| Operating Temperature (°C) | -20 to +45 |
| Operating Humidity (% RH) | ≤95 (non-condensing) |
| Overload Capacity | Up to 120% short-term |
| Weight (kg, approx. 1000kVA) | 1200-1800 |
These metrics ensure compatibility with global grids, with full routine testing for dielectric integrity, thermal rise, and waveform analysis. Custom enhancements include integrated overcurrent relays and eco-resins for sustainability.
Applications and Performance Benefits
TiraThai's autotransformers are versatile, suited for scenarios requiring compact, distortion-free voltage transformation. In industrial motor control, they provide stable step-down power for VFDs and pumps, minimizing waveform issues that could cause inefficiencies. Utility substations deploy them for load balancing in distribution networks, where single-winding simplicity reduces installation time by 20-30%. Renewable energy systems, such as solar inverters, benefit from customizable ratios to match varying outputs, ensuring clean grid injection without harmonics.
In commercial buildings and data centers, the low-noise, flame-retardant design enables indoor placement, supporting HVAC and IT loads with reliable, unmanned operation. Jinguan Electric's global installations demonstrate 99.95% uptime, 15-20% energy savings from low losses, and MTBF over 50,000 hours, ideal for continuous-duty environments free from corrosive or dusty conditions.
Why Choose TiraThai by Jinguan Electric?
TiraThai, as Jinguan Electric's sub-brand, offers autotransformer excellence backed by 45+ years of innovation. Our single-winding design provides material savings, zero distortion, and full customization, surpassing standards. With certifications like UL and CE, plus sustainable VPI processes, we ensure 25% lower costs and superior reliability for global users.
Expanded FAQ Section
How are TiraThai transformers shipped internationally? Shipped via sea, rail, or truck for global delivery. Main body in bulk packaging for stability, accessories in wooden cases to endure transit stresses.
Can TiraThai products be customized? Yes, tailored for voltage, frequency, capacity, and regional specs through Jinguan Electric's engineering team.
What warranty do you provide? At least two years comprehensive coverage for defects, performance, and materials, with extensions available.
Is Factory Acceptance Testing (FAT) supported? Standard: Full electrical, thermal, and insulation tests per unit, with client witnessing in-person or remotely.
Do you provide after-sales engineering support? Yes, Jinguan Electric assigns engineers for installation guidance, troubleshooting, and ongoing inquiries.
What ensures no waveform distortion? Single-winding balanced flux paths maintain clean output, verified per national testing standards.
Are they suitable for unmanned operation? Yes, overcurrent protection and dry-type design enable continuous, maintenance-free performance.
Certifications and Quality Assurance
TiraThai products, supplied through Jinguan Electric, undergo national type testing: UL, CUL, CCC, CQC, CTQC, CE, SGS, and mandatory approvals. Certified to ISO9001 (quality), ISO14001 (environment), and ISO45001 (health & safety), ensuring VDE0550, IEC439, JB5555, and GB226 compliance for global excellence.
Contact Us Today
Transform efficiently with TiraThai's Autotransformers. For quotes or consultations:
- WhatsApp: +8613037600603
- Email: [email protected] or [email protected]
Our team responds within 24 hours.
