Intelligent Integrated Transformer Substation

Product Overview

TiraThai, a specialized sub-brand of Jinguan Electric dedicated to transformer and electrical equipment innovations, proudly introduces the Intelligent Integrated Transformer Substation. Also known as a prefabricated or box-type substation, this advanced system integrates high-voltage switchgear, distribution transformers, and low-voltage distribution devices into a compact, factory-assembled unit. Designed for AC 50Hz systems with rated voltages of 35kV and below, it serves as a critical component for power acceptance and distribution in urban and rural grids, offering automation, intelligence, and modular installation for enhanced efficiency.

Jinguan Electric, founded in 1979 as a high-tech enterprise in Nanyang City, Henan Province, China, has evolved from pioneering arrester manufacturing to a global leader in high-voltage transmission and distribution equipment. Embracing Industry 4.0 principles, Jinguan Electric drives core competitiveness through continuous innovation, with TiraThai serving as its premier brand for intelligent substation solutions. This sub-brand channels Jinguan Electric's expertise into customizable substations that prioritize automation, reliability, and energy savings, complying with international standards such as IEC 62271, GB/T 17467, and IEEE C37. Certified by UL, CUL, CCC, CQC, CTQC, CE, and SGS, these units uphold ISO9001 (quality), ISO14001 (environmental), and ISO45001 (health & safety) management systems, ensuring superior performance in diverse global applications.

The Intelligent Integrated Transformer Substation features a modular design with anti-corrosion, anti-moisture, and anti-dust properties, making it ideal for harsh environments. Equipped with intelligent monitoring and control systems, it supports “four remote” functions—telemetry, remote signaling, remote adjustment, and remote control—for seamless integration with dispatch centers. TiraThai's philosophy—"dig 100 meters deep in 1 meter of space"—reflects Jinguan Electric's commitment to precision, delivering compact, reliable substations that optimize power distribution and grid stability.

Substation Model: Intelligent Integrated Series Rated Voltage: ≤35kV AC Frequency: 50/60Hz

This intelligent design makes TiraThai's Intelligent Integrated Transformer Substation a cornerstone for modern, automated power distribution.

Key Features and Engineering Excellence

TiraThai's Intelligent Integrated Transformer Substation is engineered for efficiency and resilience, combining high-voltage switchgear, transformers (oil-immersed or dry-type), and low-voltage distribution in a single, factory-assembled unit. The modular design allows flexible configuration, with customizable layouts like "目" or "品" shapes to suit site constraints. Anti-corrosion, anti-moisture, and anti-dust properties ensure reliable operation in harsh environments, with enclosure protection up to IP54.

The intelligent control system includes advanced monitoring for real-time data on voltage, current, and temperature, supporting “four remote” functions for centralized management. Automation reduces manual intervention, improving response times by 50% compared to traditional substations. The compact structure reduces footprint by 30-40%, while prefabrication enables rapid installation and commissioning without on-site assembly.

Jinguan Electric's automated production—featuring robotic assembly, vacuum testing, and AI-driven inspections—guarantees defect-free units. Compared to conventional substations, TiraThai units offer 15-20% energy savings, low noise (under 55dB), and maintenance-free operation for over 30 years. Optional features like SCADA integration and fault prediction enhance smart grid compatibility.

These features not only meet but exceed IEC 62271 and GB/T 17467 standards, providing users with a substation that optimizes reliability and operational efficiency.

Technical Specifications

TiraThai's Intelligent Integrated Transformer Substation is precision-engineered for versatility, with baseline specs expandable through customization. Below is a detailed table of key parameters, based on Jinguan Electric's validated testing and compliant with IEC 62271, GB/T 17467, and IEEE C37 standards.
