TiraThai, a specialized sub-brand of Jinguan Electric focused on transformer and electrical equipment innovations, proudly introduces the S13/S11/S18/S20 Transformer Iron Cores. These advanced three-phase iron cores are engineered for power transformers, delivering robust performance in electricity distribution and related facilities. Customizable to accommodate global variations in voltage, frequency, and regional specifications, the S13/S11/S18/S20 series ensures optimal efficiency, safety, environmental protection, and reliability, fully compliant with international standards such as IEC for key performance indicators.
Jinguan Electric, founded in 1979 as a high-tech enterprise in Nanyang City, Henan Province, China, has evolved from pioneering arrester manufacturing to a global leader in high-voltage transmission and distribution equipment. Embracing Industry 4.0 principles, Jinguan Electric drives core competitiveness through continuous innovation, with TiraThai serving as its premier brand for transformer core solutions. This sub-brand channels Jinguan Electric's expertise into high-quality, customizable iron cores that support seamless integration into high- and low-voltage transformers, box-type substations, and power engineering projects. Certified by UL, CUL, CCC, CQC, CTQC, CE, and SGS, these cores uphold ISO9001 (quality), ISO14001 (environmental), and ISO45001 (health & safety) management systems, backed by a minimum two-year warranty, comprehensive factory acceptance testing (FAT), and dedicated after-sales engineering support including on-site installation guidance and inquiry resolution.
The TiraThai S13/S11/S18/S20 Transformer Iron Cores are designed for three-phase configurations, with input voltages of 11kV, 15kV, or 20kV and output voltages of 380V, 400V, 440V, or 480V, supporting frequencies of 50Hz or 60Hz. Their robust construction ensures exceptional magnetic flux density and minimal losses, making them ideal for demanding power applications. TiraThai's design philosophy—"dig 100 meters deep in 1 meter of space"—reflects Jinguan Electric's commitment to precision, delivering cores that enhance transformer performance while minimizing material use and environmental impact.
Core Model: S13 / S11 / S18 / S20 Series Input Voltage Ratings: 11kV / 15kV / 20kV (Customizable) Output Voltage Ratings: 380V / 400V / 440V / 480V (Customizable) Frequency: 50/60Hz
This configurability positions TiraThai's Transformer Iron Cores as a versatile, high-efficiency choice for global power infrastructure.
Key Features and Engineering Excellence
TiraThai's S13/S11/S18/S20 Transformer Iron Cores are crafted for superior performance, leveraging high-grade materials and innovative design to achieve low no-load losses and high magnetic efficiency. The three-phase configuration utilizes premium grain-oriented silicon steel laminations with precise stacking and stepped-lap joints, minimizing hysteresis and eddy current losses for up to 20-30% better efficiency compared to standard cores. Customizable winding compatibility ensures seamless integration with oxygen-free copper or aluminum conductors, supporting overload capacities up to 120% short-term without thermal degradation.
The cores feature robust insulation systems, including epoxy resin or VPI treatments for enhanced dielectric strength and moisture resistance, enabling operation in humid or polluted environments up to 95% RH. Jinguan Electric's automated production—featuring precision core cutting, vacuum annealing, and AI-driven quality inspections—guarantees defect-free assembly with tight tolerances for optimal flux distribution. Optional enhancements like amorphous alloy variants further reduce losses by 70%, aligning with energy-saving mandates.
Compared to conventional iron cores, TiraThai models offer 15-25% material savings and extended lifespan (over 30 years), with low noise levels (under 55dB) for urban compatibility. These features not only comply with IEC standards but exceed them, providing users with cores that optimize transformer performance, reduce operational costs, and support sustainable power engineering.
Technical Specifications
TiraThai's S13/S11/S18/S20 Transformer Iron Cores are precision-engineered for reliability, with baseline specs expandable through customization. Below is a detailed table of key parameters, validated through Jinguan Electric's certified testing and compliant with IEC 60076, GB/T 6451, and IEEE C57 standards.
| Parameter | Specification Details |
|---|---|
| Phase Configuration | Three-Phase |
| Input Voltage (kV) | 11 / 15 / 20 (Customizable) |
| Output Voltage (V) | 380 / 400 / 440 / 480 (Customizable) |
| Frequency (Hz) | 50 / 60 |
| Core Material | Grain-Oriented Silicon Steel (CRGO) |
| Magnetic Flux Density (T) | 1.7-1.9 (Optimized for Low Losses) |
| No-Load Loss Reduction | 20-30% below standards (e.g., S13: 30% vs. S9) |
| Load Loss Reduction | Optimized (e.g., 1000kVA: 6500W) |
| Insulation Resistance (MΩ) | ≥1000 (at 500V DC) |
| Insulation Class | Class A (105°C rise) |
| Cooling Compatibility | ONAN / AN (Natural Air) |
| Noise Level (dB, 1m) | ≤55 |
| Efficiency (%) | >98 at full load |
| Short-Circuit Withstand | 25x rated current / 2s |
| Operating Temperature (°C) | -20 to +50 |
| Operating Humidity (% RH) | ≤95 (non-condensing) |
| Weight (kg, approx. 1000kVA) | 800-1200 (Core Only) |
These metrics support altitudes up to 1000m, with full type testing for thermal cycling, dielectric strength, and magnetic performance. Custom options include amorphous cores for ultra-low losses.
Applications and Performance Benefits
TiraThai's S13/S11/S18/S20 Transformer Iron Cores are essential for power transformers in electricity distribution networks, high- and low-voltage systems, box-type substations, and power engineering projects. In utility grids, they enable efficient step-down transformation for residential and commercial loads, with low losses reducing energy waste by 20-30%. Industrial applications, such as manufacturing and mining, leverage their overload resilience for reliable supply to heavy machinery.
Renewable energy facilities, including solar and wind farms, integrate these cores for step-up operations, ensuring stable grid injection with minimal harmonics. In urban infrastructure, the compact design fits seamlessly into pre-fabricated substations, supporting smart city expansions. Jinguan Electric's global deployments yield 99.95% uptime, 15-25% efficiency gains, and MTBF over 50,000 hours, ideal for sustainable power engineering.
Why Choose TiraThai by Jinguan Electric?
TiraThai, as Jinguan Electric's sub-brand, delivers transformer core excellence backed by 45+ years of innovation. Our S13/S11/S18/S20 series offers customizable three-phase efficiency, low losses, and IEC compliance, surpassing standards. With UL/CE certifications and sustainable materials, we ensure 20% material savings and superior reliability for global power projects.
Expanded FAQ Section
How are TiraThai cores shipped internationally? Shipped via sea, rail, or truck for global delivery. Core in bulk packaging for stability, accessories in wooden cases to withstand transit stresses.
Can TiraThai products be customized? Yes, tailored for voltage, frequency, and regional specs through Jinguan Electric's engineering team.
What warranty do you provide? At least two years comprehensive coverage for defects, performance, and materials, with extensions available.
Is Factory Acceptance Testing (FAT) supported? Standard: Full electrical, magnetic, and thermal tests per unit, with client witnessing in-person or remotely.
Do you provide after-sales engineering support? Yes, Jinguan Electric assigns engineers for installation guidance, troubleshooting, and inquiries.
What makes S13 superior to S9? S13 achieves 30% lower no-load losses and 20% reduced load losses for enhanced efficiency in distribution transformers.
Are amorphous options available? Yes, for 70% loss reduction in energy-sensitive applications.
Certifications and Quality Assurance
TiraThai products, supplied through Jinguan Electric, hold UL, CUL, CCC, CQC, CTQC, CE, and SGS certifications, plus mandatory approvals. Systems certified to ISO9001 (quality), ISO14001 (environment), and ISO45001 (health & safety), ensuring IEC 60076, GB/T 6451, and IEEE C57 compliance for global excellence.
