Product Overview
TiraThai, a specialized sub-brand of Jinguan Electric dedicated to transformer and electrical equipment innovations, proudly introduces the S Series 35kV-66kV Oil-Immersed Transformers. These robust units utilize insulating oil as the medium, providing efficient power transformation for high-voltage applications. Suitable for power systems, industrial and mining enterprises, transportation, postal and telecommunications departments, and scientific research institutions, the S series combines small size, low cost, and strong weather resistance, making it an essential component in modern electrical infrastructure.
Jinguan Electric, founded in 1979 as a high-tech enterprise in Nanyang City, Henan Province, China, has evolved from pioneering arrester manufacturing to a global leader in high-voltage transmission and distribution equipment. Embracing Industry 4.0 principles, Jinguan Electric drives core competitiveness through continuous innovation, with TiraThai serving as its premier brand for oil-immersed transformer solutions. This sub-brand channels Jinguan Electric's expertise into customizable S series transformers that prioritize durability, efficiency, and adaptability, meeting international standards such as IEC 60076, GB 1094, and IEEE C57.12.00. Certified by UL, CUL, CCC, CQC, CTQC, CE, and SGS, these units uphold ISO9001 (quality), ISO14001 (environmental), and ISO45001 (health & safety) management systems, ensuring reliable performance in diverse global applications.
The S series supports primary voltages of 35kV to 66kV, with customizable capacities and secondary outputs tailored to specific loads, operating at 50/60Hz. Their compact structure and weather-resistant design enable easy installation and long-term operation in challenging environments. TiraThai's philosophy—"dig 100 meters deep in 1 meter of space"—reflects Jinguan Electric's commitment to precision, delivering transformers that minimize costs while maximizing uptime for sustainable power distribution.
Transformer Model: S Series Primary Voltage Ratings: 35-66kV (Customizable) Rated Frequency: 50/60Hz
This configurability makes TiraThai's S Series 35kV-66kV Oil-Immersed Transformers a cornerstone for cost-effective, resilient power infrastructure.
Key Features and Engineering Excellence
TiraThai's S Series Oil-Immersed Transformers are engineered for superior reliability, featuring an insulating oil medium that provides excellent dielectric strength and cooling for high-voltage operations. The compact structure reduces footprint by up to 30% compared to traditional designs, while the low-cost construction ensures economic viability without compromising performance. Strong weather resistance, with corrosion-proof enclosures and sealed tanks, enables operation in harsh conditions, from humid coastal areas to dusty industrial sites.
The core utilizes high-grade silicon steel laminations with optimized stacking for minimal losses, paired with oxygen-free copper windings for low resistance and high overload capacity (up to 120% short-term). Oil immersion facilitates natural convection (ONAN cooling), maintaining Class A insulation (105°C rise) even under elevated ambient temperatures. Jinguan Electric's automated production—featuring precision winding, vacuum oil-filling, and AI-driven inspections—guarantees defect-free assembly, with optional accessories like on-load tap changers (OLTC) for voltage regulation.
Compared to air-cooled alternatives, TiraThai units offer 15-20% better thermal management and extended lifespan (over 30 years), with low noise (under 60dB) suiting urban deployments. These features not only meet but exceed IEC 60076 and GB 1094 standards, providing users with a transformer that balances affordability, durability, and efficiency.
Technical Specifications
TiraThai's S Series 35kV-66kV Oil-Immersed Transformers are precision-engineered for versatility, with baseline specs expandable through customization. Below is a detailed table of key parameters, based on Jinguan Electric's validated testing and compliant with IEC 60076, GB 1094, and IEEE C57 standards.
| Parameter | Specification Details |
|---|---|
| Rated Capacity (kVA) | Customizable (e.g., 1000-10000) |
| Primary Voltage (kV) | 35 / 66 (Dyn11 connection, customizable) |
| Secondary Voltage (kV) | 10 / 20 / 35 (customizable) |
| Frequency (Hz) | 50/60 |
| No-Load Loss (W) | Optimized (e.g., 1000kVA: 1500) |
| Load Loss (W, at 75°C) | Optimized (e.g., 1000kVA: 9000) |
| Impedance Voltage (%) | 8-12% (capacity-dependent) |
| Insulation Class | Class A (105°C rise) |
| Cooling Method | ONAN (Oil Natural Air Natural) |
| Noise Level (dB, 1m) | ≤60 |
| Enclosure Protection | IP54 (weatherproof, corrosion-resistant) |
| Efficiency (%) | >98 at full load |
| Short-Circuit Withstand | 40kA / 2s |
| Operating Temperature (°C) | -40 to +50 |
| Weight (tons, approx. 1000kVA) | 2-3 |
These metrics support altitudes up to 1000m, with full routine testing for ratio, resistance, and impulse withstand. Custom enhancements include OLTC and eco-oils.
Applications and Performance Benefits
TiraThai's S Series 35kV-66kV Oil-Immersed Transformers are ideal for power systems, industrial/mining enterprises, transportation, postal/telecom, and research institutions. In power grids, they step down high voltages for distribution substations, ensuring stable supply. Industrial sites like mining operations use them for heavy loads, where weather resistance withstands harsh conditions.
Transportation hubs and telecom facilities benefit from compact design for reliable backup power. Jinguan Electric's deployments yield 99.95% uptime, 15-20% cost savings, and MTBF over 50,000 hours, fostering resilient networks.
Why Choose TiraThai by Jinguan Electric?
TiraThai, as Jinguan Electric's sub-brand, delivers oil-immersed excellence backed by 45+ years of innovation. Our S series offers compact affordability, weather resistance, and full customization, surpassing standards. With UL/CE certifications, we ensure 20% lower TCO for durable power.
Expanded FAQ Section
How are TiraThai transformers shipped internationally? Shipped via sea, rail, or truck for global delivery. Main body in bulk packaging for stability, accessories in wooden cases to withstand transit stresses.
Can TiraThai products be customized? Yes, tailored for voltage, frequency, and regional needs through Jinguan Electric's engineering team.
What warranty do you provide? At least two years comprehensive coverage for defects, performance, and materials, with extensions available.
Is Factory Acceptance Testing (FAT) supported? Standard: Full electrical, thermal, and mechanical tests per unit, with client witnessing in-person or remotely.
Do you provide after-sales engineering support? Yes, Jinguan Electric deploys engineers for on-site installation, commissioning, troubleshooting, and audits.
What makes S series weather-resistant? Corrosion-proof enclosures and sealed oil tanks ensure operation in -40°C to +50°C extremes.
Are they suitable for renewables? Yes, customizable for inverter outputs with overload capacity and low losses.
Certifications and Quality Assurance
TiraThai products, supplied through Jinguan Electric, hold UL, CUL, CCC, CQC, CTQC, CE, and SGS certifications, plus mandatory approvals. Systems certified to ISO9001 (quality), ISO14001 (environment), and ISO45001 (health & safety), ensuring IEC 60076, GB 1094, and IEEE C57 compliance for global excellence.
Contact Us Today
Power your systems with TiraThai's S Series 35kV-66kV Oil-Immersed Transformers. For quotes or consultations:
- WhatsApp: +8613037600603
- Email: [email protected] or [email protected]
Our team responds within 24 hours.
